Rincian produk
Nama merek: DDW
Sertifikasi: CE/ROHS/FCC/UL/ISO/3C
Nomor model: DDW-LEDFU
Syarat Pembayaran & Pengiriman
Kuantitas min Order: 1~10
Kemasan rincian: Karton berkualitas dengan kemasan kotak kayu penuh / Kasus penerbangan
Waktu pengiriman: 7-20 hari
Lapangan Piksel: |
P1.56/P1.95/P2.5/P2.604/P2.976/P3.91 |
Tipe LED: |
/SMD1212/SMD1515/SMD2121 |
Kecerahan: |
500-1200cd/m² |
Tingkat Penyegaran: |
3840hz |
Ukuran kabinet: |
500x250/750x250/1000x250mm |
Ukuran Modul: |
250x250mm |
Lapangan Piksel: |
P1.56/P1.95/P2.5/P2.604/P2.976/P3.91 |
Tipe LED: |
/SMD1212/SMD1515/SMD2121 |
Kecerahan: |
500-1200cd/m² |
Tingkat Penyegaran: |
3840hz |
Ukuran kabinet: |
500x250/750x250/1000x250mm |
Ukuran Modul: |
250x250mm |
| jenis LED | SMD1212 | SMD1515 | SMD1515 | SMD1515 | SMD1515 | SMD2121 |
| Kepadatan fisik (titik/sq.m) | 409600 | 262144 | 160000 | 147456 | 112896 | 65536 |
| Resolusi modul | 160X160 | 128X128 | 100X100 | 96X96 | 84X84 | 64X64 |
| Dimensi modul (mm) | 250X250 | 250X250 | 250X250 | 250X250 | 250X250 | 250X250 |
| Jumlah modul (W×H) | 4X1/3X1/2X1 | 4X1/3X1/2X1 | 4X1/3X1/2X1 | 4X1/3X1/2X1 | 4X1/3X1/2X1 | 4X1/3X1/2X1 |
| Resolusi panel | 640X160 | 512X128 | 400X100 | 384X96 | 336X84 | 256X64 |
| Pemeliharaan | Layanan akses depan | Layanan akses depan | Layanan akses depan | Layanan akses depan | Layanan akses depan | Layanan akses depan |
| Bahan kabinet | Aluminium | Aluminium | Aluminium | Aluminium | Aluminium | Aluminium |
| Kalibrasi piksel | Ya | Ya | Ya | Ya | Ya | Ya |
| Kecerahan (cd/m²) | 500 | 700 | 800 | 800 | 800-1000 | 1000-1200 |
| Suhu warna (K) | 3200-9300 Opsional | 3200-9300 Opsional | 3200-9300 Opsional | 3200-9300 Opsional | 3200-9300 Opsional | 3200-9300 Opsional |
| Skala abu-abu (bit) | 14/16 Opsional | 14/16 Opsional | 14/16 Opsional | 14/16 Opsional | 14/16 Opsional | 14/16 Opsional |
| Sudut pandang (V/H) | 160°/160° | 160°/160° | 160°/160° | 160°/160° | 160°/160° | 160°/160° |
| Keseragaman Kecerahan/Warna | ≥97% | ≥97% | ≥97% | ≥97% | ≥97% | ≥97% |
| kontras | 6000:01:00 | 5000:01:00 | 5000:01:00 | 5000:01:00 | 5000:01:00 | 5000:01:00 |
| Tingkat frekuensi | 50/60 | 50/60 | 50/60 | 50/60 | 50/60 | 50/60 |
| Modus berkendara | 1/40Pindai | 1/32 Pindai | 1/25 Pindai | 1/32 Pindai | 1/28 Pindai | 1/16 Pindai |
| Konsumsi daya maks (w/m²) | 480 | 600 | 600 | 600 | 600 | 800 |
| Rata-ratakonsumsi daya (w/m²) | 100-200 | 100-200 | 100-200 | 100-200 | 100-200 | 100-200 |
| Tenaga listrik | AC90-264V | AC90-264V | AC90-264V | AC90-264V | AC90-264V | AC90-264V |
| 47-63Hz | 47-63Hz | 47-63Hz | 47-63Hz | 47-63Hz | 47-63Hz | |
